Design services

James Fisher Nuclear (JFN) provides industry with a diverse range of standard and bespoke designs, which are robust, reliable, maintainable and cost effective.

Products supplied range from components and sub-assemblies through to rigs, instruments, systems and skid-mounted turn-key plants for processing hazardous materials.

JFN is able to support a project from the concept phase, through the development and design delivery and has a substantial design capacity with more than 75 3D and 175 2D CAD licences. JFN is additionally able to support the full project lifecycle including training, operations, maintenance and decommissioning through the provision of structured support documentation.

All JFN design and manufacturing work is carried out to strict environmental, health and safety and quality standards.

Although 2D design services are maintained and often utilized on legacy mechanical designs, complex mechanical designs typically use JFN solid modelling capabilities.

Electrical design services utilise AutoCAD, Relux, Amtech, EPLAN and Wiseimage to support equipment design or as standalone packages in respect of building infrastructure.

Programmable electronic systems and control system design includes appropriate configuration management and software lifecycle processes, prior to program coding.

All designs produced are validated and verified by the in-house analysis division.
